The IPC-HF3500 is a Box Camera from Dahua that comes with 5MP, 1/2″ 8FPS@5MP/25FPS@1080,P ICR DWDR Audio features. Features: 1/2.5” 5Megapixel Progressive Scan Aptina CMOS H.264 & MJPEG dual-stream encoding Max 8fps@5.0M(2536×1920)&25/30fps@1080P(1920×1080) DWDR, Day/Night(ICR), 2DNR, AWB, AGC, BLC Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS Built-in 1/1 alarm in/out PoE( not for –W series); Wi-Fi(-W only) SD memory Specifications: Model IPC-HF3500 Camera Image Sensor 1/2.5” 5Megapixel Aptina CMOS Effective Pixels 2592(H)×1944(V) Scanning System Progressive Electronic Shutter Speed Auto/Manual,1/3~1/10000s Min. Illumination Color: 0. 6Lux/F1.2, B/W: 0.08Lux/F1.2 S/N Ratio >50dB Video Output 1 channel, BNC(1.0Vp-p, 75?) Camera Features Day/Night Auto(ICR) / Color / B/W Backlight Compensation BLC / HLC / DWDR White Balance Auto Gain Control Auto/Manual Noise Reduction 2D Privacy Masking Up to 4 areas Lens Mount Type C/CS Video Compression H.264 / MJPEG Resolution 5.0M(2560×1920) / 3.0M(2048×1536) /1080P(1920×1080) / 720P(1280×720) /D1(704×576) / CIF(352×288) Frame Rate Main Stream 5M(1-8fps)/3M(1-15fps)/1080P/720P(1 ~ 25/30fps) Sub Stream D1/CIF(1 ~ 25/30fps) Bit Rate H.264: 32K ~ 8192Kbps, MJPEG: 32K ~ 20480Kbps Audio Compression G.711a / G.711u(64kbps) / PCM(128kbps) Interface 1/1 channel In/Out Network Ethernet RJ-45 (10/100Base-T) Wi-Fi N/A Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour ONVIF ONVIF Ver. 2.0 Max. User Access 10 users Smart Phone iPhone, iPad, Android, Windows Phone Auxiliary Interface Memory Slot SD, Max 32GB RS485 1 Alarm 1/1 channel In/Out General Power Supply DC12V/AC24V, PoE(802.3af) Power Consumption <6W Working Environment -10°C~+60°C, 10%~90% Dimensions(W×D×H) 70mm×149.5mm×63.2mm Weight 650g
